RUCKUS R760 Wi-Fi 6E Indoor Access Point | 901-R760-WW00
£1,407.82 inc VAT
901-R760-WW00
Availability:
Couldn't load pickup availability
The RUCKUS R760 is an ultra high performance Wi-Fi 6E 4x4:4 Indoor Access Point with 8.35Gbps max rate and embedded IoT.
Key features
- Wi-Fi 6E (802.11ax) – tri-band (2.4/5/6GHz)
- Supports 12 spatial streams (4x4:4 in 6GHz, 4x4:4 in 5GHz, 4x4:4 in 2.4GHz)
- 8.35Gbps – High-speed connectivity
- Up to 1536 client connections and 36 SSID's
- 10GbE ethernet port
- OFDMA & MU-MIMO – Efficient multi-device handling
- BeamFlex+ – AI-driven adaptive antennas
- IoT-ready – Built-in BLE/Zigbee support
- SmartMesh™ – Self-healing wireless backhaul
- RUCKUS AI – Predictive network optimization
- Ultra high performane for ultrahigh-density environments like convention centers and school auditoriums.
Options
Cloud Management Licenses
Options, spares and accessories
Downloads
Datasheet
About this product
The RUCKUS R760 is a top‑tier Wi‑Fi 6E access point designed for maximum capacity and performance. This tri‑band, tri‑radio model operates simultaneously in the 6GHz, 5GHz, and 2.4GHz bands, delivering 12 spatial streams (4x4:4 in each band). With support for OFDMA, MU‑MIMO, and Target Wake Time (TWT), the R760 can serve up to 1,536 connected users while maintaining exceptional coverage, throughput, and efficiency in extremely dense environments. A 10Gbps multi‑gigabit Ethernet uplink ensures the wired backhaul can fully support the AP’s high wireless capacity.
Beyond Wi‑Fi, the R760 incorporates integrated BLE and Zigbee IoT radios, enabling seamless use of non‑Wi‑Fi wireless technologies when paired with the RUCKUS IoT Suite. This allows organisations to unify their connectivity needs on a single, converged infrastructure rather than maintaining separate wireless systems.
Purpose‑built for high‑demand indoor locations—such as stadiums, transit hubs, auditoriums, conference centres, and other heavily trafficked facilities—the R760 excels in environments requiring robust support for bandwidth‑intensive applications, including 4K media streaming, while also ensuring high reliability for latency‑sensitive voice and data services.
The R760’s performance is further enhanced by RUCKUS’ exclusive Ultra‑High‑Density Technology Suite, which leverages patented optimisations and intelligent algorithms to elevate network capacity and efficiency. Key features include:
- Airtime Decongestion – Improves throughput by optimising airtime usage in congested RF conditions
- Transient Client Management – Minimises interference from devices that probe for networks but never connect
- BeamFlex adaptive antenna technology – Extends coverage and boosts performance using dynamic, multi‑directional antenna patterns
Whether deployed in small installations or scaled across thousands of sites, the R760 integrates smoothly with RUCKUS’ extensive range of cloud‑based and on‑premises management platforms, offering flexible, streamlined administration for networks of any size.
