Aruba AP-514 Access Point Antenna Options


£8.51
£8.51
£8.51

JW009A

20



Note : Please refer to the Aruba AP-514 access point datasheet and ordering guide before selecting antennas.

JW009A AP-ANT-1W 2.4-2.5GHz (4dBi) / 4.9-5.875GHz (6dBi), high-gain dual-band omni-directional direct-mount articulating antenna (white)
JW001A AP-ANT-13B 2.4-2.5GHz (2.3dBi) / 4.9-5.9GHz (4.0dBi), down-tilt, smallest form factor omni-directional antenna, w/ ceiling mount hardware
JW004A AP-ANT-19 dual Band, omni-directional 3dBi/6dBi, indoor/outdoor, 36 inch pigtail cable. Pole mount, I-beam, and ceiling tile mount hardware included
JW011A AP-ANT-20W 2.4-2.5GHz (2dBi) / 4.9-5.875GHz (2dBi), compact dual-band omni-directional direct-mount articulating antenna (white)
JW017A AP-ANT-40 dual-band, 4/5dBi, 4 element MIMO downtilt omni antenna, ceiling mount
JW018A AP-ANT-45 dual-band, 5dBi, 4 element MIMO 90 x 90 degrees sector antenna, wall mount
JW019A AP-ANT-48 dual-band, 8.5dBi, 4 element MIMO 60 x 60 degrees sector antenna, wall mount
JW021A AP-ANT-MNT-4 AP-ANT-48 Azimuth and Elevation Adjustable Mount Kit
JW022A AP-ANT-MNT-5 AP-ANT-45 Azimuth and Elevation Adjustable Mount Kit

Note : Please refer to the Aruba AP-514 access point datasheet and ordering guide before selecting antennas.

JW009A AP-ANT-1W 2.4-2.5GHz (4dBi) / 4.9-5.875GHz (6dBi), high-gain dual-band omni-directional direct-mount articulating antenna (white)
JW001A AP-ANT-13B 2.4-2.5GHz (2.3dBi) / 4.9-5.9GHz (4.0dBi), down-tilt, smallest form factor omni-directional antenna, w/ ceiling mount hardware
JW004A AP-ANT-19 dual Band, omni-directional 3dBi/6dBi, indoor/outdoor, 36 inch pigtail cable. Pole mount, I-beam, and ceiling tile mount hardware included
JW011A AP-ANT-20W 2.4-2.5GHz (2dBi) / 4.9-5.875GHz (2dBi), compact dual-band omni-directional direct-mount articulating antenna (white)
JW017A AP-ANT-40 dual-band, 4/5dBi, 4 element MIMO downtilt omni antenna, ceiling mount
JW018A AP-ANT-45 dual-band, 5dBi, 4 element MIMO 90 x 90 degrees sector antenna, wall mount
JW019A AP-ANT-48 dual-band, 8.5dBi, 4 element MIMO 60 x 60 degrees sector antenna, wall mount
JW021A AP-ANT-MNT-4 AP-ANT-48 Azimuth and Elevation Adjustable Mount Kit
JW022A AP-ANT-MNT-5 AP-ANT-45 Azimuth and Elevation Adjustable Mount Kit
